Siemens SIMATIC IOT2040 Setting Up

2 Requirements
IOT2000 Setting Up
Version 2.1, 08/2017
8
 Siemens AG 2017 All rights reserved
Table 2-1
No.
Description
1
Aperture for wall-mounting
2
Designation for integration of antennas
3
Connection for Power Supply
4
COM-Interfaces (RS232/485)
5
5 LED’s, 1 programmable USER LED
6
Left cap
7
Right cap
8
Aperture to lock the right cap
9
RESET button for the CPU
10
USER button
11
Ethernet Interface 10/100 Mbps
12
Ethernet Interface 10/100 Mbps
13
USB Typ Mini-B
14
USB Typ A
Micro-SD Card
SIMATIC IOT2000 can be operated with a Yocto Linux Operating System, which
requires the use of a Micro-SD Card.
The requirement for using SIMATIC IOT2000 with Yocto Linux Operating System is
a Micro-SD Card with storage capacity from 8GB up to 32GB.
Engineering Station
To work with the SIMATIC IOT2000 an Engineering Station is required. In this
Setting Up a PC with Windows 7 Enterprise is used.
The Engineering Station has to include the following Interfaces:
 SD Card Slot
 Ethernet Port
Ethernet cable
For an Ethernet Connection between the Engineering Station and the SIMATIC
IOT2000 in order to establish a SSH connection and to download the Eclipse
projects an Ethernet cable is required.
Power supply
In order to run the SIMATIC IOT2000 a power supply is required.
This power supply has to provide between 9 and 36V DC.
