Siemens SIMATIC IPC477D Operating Manual

BIOS Setup (SCU)
3.9 BIOS Setup settings
BIOS Description
Operating Manual, 05/2016, A5E33664825-AB
41
Setup parameter
IPC6x7
IPC8x7
IPC4x7
IPC2x7
Field programming
device
Mode
3
Bi-directional
DMA Channel
3
DMA 1
CAN
1
Auto
Base I/O address
4
5400
Interrupt
4
IRQ5
Onboard PROFINET
1
PROFINET
Enabled Enabled
PCI – MPI / DP
1
Enabled
Enabled
Enabled
Audio 5
Auto
Enabled
Auto
Azalia internal HDMI codec
5
Enabled
Enabled
Onboard Ethernet 1
(LAN 1, X1 P1)
Enabled Enabled Enabled Enabled
Onboard Ethernet 2
(LAN 2, X2 P1)
Enabled Enabled Enabled Enabled
WLAN
6
Last State
Cardbus + SD-Card
6
Enabled
Touchpad
6
Enabled
1
Depending on the ordered device configuration
2
Only visible if the associated parameter "Internal COM #" is enabled.
3
Only visible if "Internal LPT" is enabled.
4
Only visible if "CAN" is enabled.
5
Only available if an Azalia HD audio controller is installed.
6
Only with Field programming device
Advanced > SATA / IDE Configuration
Setup parameter
IPC6x7
IPC8x7
IPC4x7
IPC2x7
Field programming
device
SATA Controller
Enabled
Enabled
HDC Configure As
Chipset SATA mode
AHCI
1
AHCI AHCI AHCI
SATA Port 0 Device Type
Hard Disk Drive
Hard Disk Drive
SATA Port 1 Device Type Hard Disk Drive Hard Disk Drive
SATA Port 2 Device Type
Hard Disk Drive
Hard Disk Drive
SATA Port 2 Hot Plug
Disabled
1
Depending on the ordered device configuration
Advanced > Fan Control Configuration
1
Setup parameter
IPC6x7
IPC8x7
IPC4x7
IPC2x7
Field programming
device
Fan Control Mode
1
Standard
1
Depending on the ordered device configuration
