Siemens SIMATIC NET CP 5622 User Manual

CP 5622
Operating Instructions, 05/2021, C79000-G8976-C279-04
21
Technical data
5
Technical specifications of the CP 5622
Connection to PROFIBUS
Amount
1
Transmission speeds
9.6 kbps, 19.2 kbps, 45.45 kbps,
93.75 kbps, 187.5 kbps, 500 kbps,
1.5 Mbps, 3 Mbps, 6 Mbps, 12 Mbps
Design
9-pin D-sub female connector with screw
locking mechanism
RS-485 (ungrounded within the SELV limits)
Properties
Grounded cable shield
Floating interface signals
Connection to PG/PC
PCI Express x1
V 2.0 plug and play
Can also be operated in x4, x8 or x16.
Electrical specifications of the PCI plug-in connector
Operating voltage
Rated voltage
3.3 VDC and 12 VDC
Permitted range
3.0... 3.6 V DC for 3.3 V DC
11.0... 13.0 V DC for 12 V DC
Properties
Safety extra low voltage (SELV) to EN
60950
Current consumption
Typical
300 mA at 3.3 V
250 mA at 12 V
Effective power loss
Typical
4.0 W
Permitted ambient conditions
Operating conditions
Temperature
(EN 60068-2-1+2)
Temperature change max.
+5 to +50°C
≤ 10 K/h
Relative humidity
(EN 60068-2-78)
≤ 85% at 30 °C, no condensation
Rapid temperature change
(EN 60068-2-14)
+5 … +50 °C, 5 cycles
Storage and transportation conditions
Temperature
(EN 60068-2-1+2)
Maximum temperature change
-20 to +60 °C
≤ 20 K/h
Relative humidity
(EN 60068-2-78)
≤ 95% at +25 °C to +55°C, no condensation
Fast temperature change
• to EN 60068-2-14
•
to EN 60068-2-30
-20 to +60 ℃, 2 cycles
+25 to +55°C at 95% humidity
Vibration, operating
(EN 60068-2-6)
Frequency 10 to 58 Hz
Frequency 58 to 500 Hz
Number of cycles
0.075 mm amplitude
10 m/s
2
Acceleration
10/axis
