RUGGEDCOM RSG907R
Installation Guide
Chapter 5
Technical Specifications
Fiber Optic Ethernet Port Specifications 31
Standard 10 Mbps Ports 100 Mbps Ports 1000 Mbps Ports Description
IEEE 802.3z
ü
1000Base-LX
IEEE 802.3ab
ü
1000Base-Tx
IEEE 802.3ad
ü
Link Aggregation
IEEE 802.1D
ü ü ü
MAC Bridges
IEEE 802.1D
ü ü ü
Spanning Tree Protocol (STP)
IEEE 802.1p
ü ü ü
Class of Service (CoS)
IEEE 802.1Q
ü ü ü
VLAN (Virtual LAN) Tagging
IEEE 802.1w
ü ü ü
Rapid Spanning Tree Protocol (RSTP)
IEEE 802.1x
ü ü ü
Port-Based Network Access Control
IEEE 802.1Q-2005
ü ü ü
Multiple Spanning Tree Protocol (MSTP)
IEEE 1588-2008
ü ü ü
Precision Time Protocol (PTP) Version 2
IEC 62439-2:2016
ü ü
Media Redundancy Protocol (MRP)
IEC 62439-3:2016
ü ü ü
High-Availability Seamless Redundancy
(HSR), Parallel Redundancy Protocol (PRP)
Section5.4
Fiber Optic Ethernet Port Specifications
The following details the specifications for fiber Ethernet ports that can be ordered with the RUGGEDCOM
RSG907R.
NOTE
• All optical power numbers are listed as dBm averages. To convert from average to peak, add 3 dBm.
To convert from peak to average, subtract 3 dBm.
• Maximum segment length is greatly dependent on factors such as fiber quality, and the number
of patches and splices. Consult a Siemens sales associate when determining maximum segment
distances.
Wavelength (nm)
e
Transmit
Power (dBm)
Data
Rate
(Mbps)
Mode Connector
Cable
(μm)
Transmit Receive Min Max
Receiver
Sensitivity
(dBm)
Receiver
Saturation
(dBm)
Distance
(km)
e
Power
Budget
100 MM LC 50/125 1308 1308 -22.5 -14 -31 -14 2 11
100 MM LC 62.5/125 1308 1308 -20 -14 -31 -14 2 11
e
Typical.
