Siemens SIMATIC NET RUGGEDCOM RX1512 User Manual

Device Management
3.3 Accessing the CompactFlash Card
CAUTION
Configuration hazard – risk of data corruption/loss. Do not remove or insert the CF
card when the device is powered on.
The CF card should only be removed in the following scenarios:
• The chassis is defective (with the exception of power and media modules)
• The CF card is deemed defective or corrupt
• The device is rendered non-functional due to a serious configuration error, data
corruption, or hardware fault
CAUTION
Configuration hazard – risk of data corruption/loss. The following will void the war-
ranty and potentially result in configuration data corruption/loss:
• Using a CF card not approved by Siemens for use with this device
• Removing the CF card in any scenario other than those described in this section
Inserting the CF card
To insert the CF card into the device, do the following:
NOTICE
The device should only be powered on when the CF card is present.
1. Make sure the device is powered down.
2. Remove the CF card access panel.
RUGGEDCOM RX1512
Installation Manual, 07/2019, C79000-G8976-1057
17
All manuals and user guides at all-guides.com
all-guides.com

Siemens SIMATIC NET RUGGEDCOM RX1512 Specifications

General

Switch Capacity	24 Gbps
MAC Address Table	8K
VLANs	256
Protection Rating	IP30
Ingress Protection	IP30
Layer	Layer 2
Product Type	Industrial Ethernet Switch
Category	Industrial
Jumbo Frames	Up to 9 kB
Power Supply	24 VDC or 110/230 VAC
Operating Temperature	-40°C to +75°C
Mounting	DIN Rail
Redundancy	RSTP, MRP
Management	Web-based, SNMP
Certifications	CE, UL, cUL, FCC
Ports	12 x 10/100/1000Base-T(X) ports, 4 x 100/1000Base-X SFP ports
