Chapter 5
Dimension Drawings
RUGGEDCOM RX1500
Installation Guide
48
11.7
21.1
28.7
51.1
161.0
212.1
4.7
6.35
463.8
31.8
Figure 55: Rack Mount Dimensions
160.0
489.2
51.6
479.0
134.6
68.8
21.1
11.7
29.0
51.1
161.0
212.1
Figure 56: Panel and Din Rail Mount Dimensions
