52 EMC and Environmental Type Tests
Description Test Levels
Signal ports 5 kV (Failsafe Relay Output)
DC Power Ports
HV Impulse
AC Power Ports
5 kV
Signal ports 2 kV
DC Power Ports 1.5 kV
Dielectric Strength
AC Power Ports 2 kV
Signal ports ± 4 kV @ 2.5 kHz
DC Power Ports
AC Power Ports
Fast Transient
Earth ground ports
± 4 kV
Signal ports 2.5 kV common mode @1MHz
DC Power Ports
Oscillatory
AC Power Ports
2.5 kV common, 1 kV differential mode @ 1 MHz
Radiated RFI Enclosure ports 35 V/m
Enclosure Contact ±2 kV, ±4 kV, ± 8 kVESD
Enclosure Air ±4 kV, ±8 kV, ±15 kV
Environmental Type Tests
Test Description Test Levels Severity Levels
IEC
60068-2-1
Cold Temperature Test Ad -40 °C (-40 °F), 16 Hours
IEC
60068-2-2
Dry Heat Test Bd 85 °C (185 °F), 16 Hours
IEC
60068-2-30
Humidity (Damp
Heat, Cyclic)
Test Db 95% (non-condensing),
55 °C (131 °F), 6 cycles
IEC
60255-21-1
Vibration 2 g @ 10-150 Hz Class 2
Shock 30 g @ 11 ms Class 2IEC
60255-21-2
Bump 10 g @ 16 ms Class 1
IEC
60255-21-3
Seismic Method A Level 2
