Description of the device
3.4 Accessories
SCALANCE W774-1 /W734-1
18 Operating Instructions, 07/2020, C79000-G8976-C325-14
Socket
Component
Description
Article number
IE POWER
M12 CABLE
CONNECTOR
PRO
Socket for the 24 VDC power supply. 4-pin, A-coded
pack of 3
6GK1907-0DC10-6AA3
Lightning protection
Component
Description
Article number
LP798-1N
Lighting protector with N/N female/female connect-
or with gas discharge technology
6GK5798-2LP00-2AA6
LP798-2N
Lighting protector with N/N female/female connect-
or with quarter wave technology
6GK5798-2LP10-2AA6
Terminating resistor
Component
Description
Article number
TI795-1N
Electrical connection
N-Connect, male
Pack of 1
6GK5795-1TN00-1AA0
3.4.1 Flexible connecting cables and antennas
3.4.1.1 Flexible connecting cables
Flexible connecting cable N-Connect/R-SMA
Flexible connecting cable for connecting an antenna to a SCALANCE W device with R-
SMA connectors, preassembled with a connector N-male and R-SMA male
Length
Article number
0.3 m
6XV1875-5CE30
1 m
6XV1875-5CH10
2 m
6XV1875-5CH20
5 m
6XV1875-5CH50
10 m
6XV1875-5CN10
