4.2.3 SCALANCE XB213-3
The following figure shows an overview of the components of the SCALANCE XB213-3.
① Optical ports with port LEDs
② Power supply with connector for grounding
③ Serial interface
④ Electrical ports with port LEDs
⑤ "RESET" button (rear)
⑥ Fault LED
Description of the device
4.2 Device views
SCALANCE XB-200
22 Operating Instructions, 03/2020, C79000-G8976-C359-09
