4.2 Device views
4.2.1 SCALANCE XB208
The following figure shows an overview of the components of the SCALANCE XB208.
① Electrical ports with port LEDs
② Power supply with connector for grounding
③ Serial interface
④ "RESET" button (rear)
⑤ Fault LED
