8.2 Technical specifications of the SCALANCE XB205-3 (SC)
The following technical specifications apply to the SCALANCE XB205-3 (SC).
Technical specifications
Attachment to Industrial Ethernet
Electrical connectors Quantity 5
Connector RJ-45 jack
Properties Half/full duplex, MDI‑X pinning
Transmission speed 10 / 100 Mbps
Optical connectors Quantity 3
Connector SC socket
Properties Full duplex acc. to 100Base-FX
Transmission speed 100 Mbps
Cable type Multimode glass FO cable
Transmitter output (optical)
● Minimum
● Maximum
● -19 dBm
● -14 dBm
Receiver input
● Sensitivity min.
● Input power max.
● -34 dBm
● -3 dBm
Cable cross-section
● 50/125 μm
● 62.5/125 μm
Cable length
● 0 ... 5 km
● 0 ... 5 km
Attenuation
● ≤ 1 dB/km at 1310 nm; 1200 MHz * km
● ≤ 1 dB/km at 1310 nm; 1200 MHz * km
Diagnostics interface
Serial interface Quantity 1
Connector RJ-11 jack
Electrical data
Power supply Rated voltage 24 VDC
Voltage range 19.2 to 28.8 VDC Safety Extra Low Voltage
(SELV)
Design Terminal block, 3 terminals
Properties Implemented redundantly
Current consumption at 24 VDC 300 mA
*)
Effective power loss at 24 VDC 7.2 W
Fusing F 2.5 A / 125 V
Permitted ambient conditions
Ambient temperature During operation up to 2000 m 0 ℃ to +60 ℃
During storage -40 ℃ to +70 ℃
During transportation -40 ℃ to +70 ℃
Relative humidity During operation at 25 ℃ ≤ 95 % no condensation
Housing, dimensions and weight
Design compact
Technical specifications
8.2 Technical specifications of the SCALANCE XB205-3 (SC)
SCALANCE XB-200
50 Operating Instructions, 03/2020, C79000-G8976-C359-09
