Plant bus
Terminal bus
Fieldbus
PCS 7 OS clients
PCS 7 OS server BATCH serverRoute Control server
Archive server
OpenPCS 7 station
PCS 7 OS client
OPC client
S7-400S7-400S7-400
ET 200ET 200ET 200
5.3.2 OpenPCS 7 combined with an OS server or CAS
OpenPCS 7 on a server
PCS 7 supports the OpenPCS 7 station on the following servers:
● OS server
● Central archive server (CAS)
The preferred configuration for large PCS 7plants is a separate OpenPCS 7 station.
System configurations
5.3 OpenPCS 7 combined with an OS
OpenPCS 7
Function Manual, 05/2012, A5E02780178-02 35
