Designation Technical Specifications
Electromagnetic compatibility (EMC)
Emitted interference
Limit class B to EN 55022 = CISPR 22
Interference
immunity on signal
lines
"2kV (to IEC 801-4/
IEC 1000-4-4; Burst)
Interference
immunity against
discharging of static
electricity
"6kV Contact discharge
(to IEC 801-2/IEC 1000-4-2;
ESD)
"8kV Air discharge (to IEC 801-2/IEC
1000-4-2; ESD)
Highfrequency
radiation
10 V with 80% amplitude modulation at
1 kHz, 10 kHz - 80 MHz (to ENV 50141)
10 V/m with 80% amplitude modulation at 1
kHz, 80 Mhz - 1GHz (to ENV 50140)
10 V/m pulse-modulated 50% load factor at
900 MHz (to ENV 50204)
Climatic conditions
Temperature
operation
storage/
shipping
Tested to DIN IEC 68-2-1, DIN IEC 68-2-2
"0°C to +60°C
(rate of temperature change
max. 10 °C/h)
-40°C to +70°C
(rate of temperature change
max. 20°C/h)
Relative humidity
operation
storage/
shipping
Tested to DIN IEC 68-2-3
5% to 85% at 30°C (no condensation)
5% to 93% at 40°C (no condensation)
