Properties
1.1 Power module PM-E DC24V (6ES7138-4CA01-0AA0)
Power module PM-E DC24V (6ES7138-4CA01-0AA0)
8 Manual, 04/2007, A5E01119952-02
General terminal assignment
Note
Terminals
A4 and A8 are only available at specified terminal modules.
Terminal assignment for PM-E DC24V (6ES7138-4CA01-0AA0)
Terminal
Assignment
Terminal
Assignment
Notes
2
L+
6
L+
• L+: Rated load voltage 24 VDC
• M: Chassis ground
• AUX1: Protective-conductor terminal or potential bus (freely usable
up to 230 VAC)
3
M
7
M
A4
AUX1
A8
AUX1
