The demo application
7.1 User interface of the demo application
SIMATIC RF1000
Operating Instructions, 11/2019, C79000-G8976-C432-06
53
Input box for the number of the VHL file.
address Input box for the start address as of which the transponder data is to be read
Input box for the data length of the transponder data to be read/written.
Figure 7-1 Example view of reading a serial number
The version number of the demo application is shown at the bottom right in the
application.
2. Click the "Start" button to set up the connection to the reader and start the selected
action.
Read SerNr (auto) Automatic reading of the serial number and the card type. The data
is output in the top display area.
Read Data (auto) Automatic reading of the transponder data depending on the specif-
ic card type configuration. The data is output in the bottom display
area. If no matching specific card type configuration is stored in the
reader, the error message "0x501" is output.
Read/Write (man.) Manual reading/writing of the transponder data depending on the
selected configuration file ("VHL file number") as well as the start
address and the data length ("address" and "length").
The read or write operation is initiated with the "Read Data" or
"Write Data" buttons.
The transponder data to be written or read are edited or output in
the bottom input/display area.
Configcard Transferring the configuration from the configuration card in the
antenna field to the reader. Note the the connection is terminated
after the transfer ("Stop") and must be reestablished ("Start").
3. To clear the display area, click on the "Clear" button.
4. Click on the "Stop" button to disconnect the connection to the reader.
