2 Engineering
Securely Connecting RTU3041C to TeleControl Server Basic
Entry ID: 109739240, V3.0, 07/2021
51
© Siemens AG
2021 All rights reserved
7. Select "Limit value switch" as the function.
8. Interconnect the parameters as follows:
– Input: fillLevelPercent (AM1)
– Output: fillLevel90 (DM0)
– Limit value 1: 0.9000
– Limit value 2: 0.8999
9. Add a new function block (FB3) below.
