Securely Connecting RTU3041C to TeleControl Server Basic
Entry ID: 109739240, V3.0, 07/2021
To read the data via the OPC UA Client "UaExpert", proceed as follows:
1. Assign your PG/PC "Client" an IP address in the subnet of the router (in
accordance with Table 2-1).
2. Start the SINEMA Remote Connect Client.
3. Connect to your SINEMA Remote Connect Server by entering the static IP
address of your router, the port (static IP address:1443), and the login data of
the previously created user
(see Section 2.2.1, Step 13).
4. Then, click "Log in".
5. After the successful login, establish a VPN tunnel.
6. After the VPN connection is established, allow communication to the SINEMA
RC LAN1 and the RTU3041C.
7. Start "UaExpert" (PG/PC "Client").
8. Click the "Add Server" button.
