Description
1.2 System components
SIMOTION D410
16 Commissioning Manual, 02/2012
The most important system components and their functions are listed in the following table.
Table 1- 1 System components
Component Function
SIMOTION D410 ... is the central motion control module.
The module contains the programmable SIMOTION Runtime in
SIMOTION D410 and the SINAMICS S120 drive software.
You can use the integrated rapid digital I/Os as:
• Homing inputs
• Inputs for measuring inputs
• User-addressable process I/Os
• Outputs for fast output cams
The measuring sockets can output any analog signals.
The DRIVE-CLiQ interface permits a fast connection to the SINAMICS drive
components.
System software The system software is delivered separately on a CompactFlash Card (not
included in the scope of delivery).
Note:
An additional license is not required for the real axis technology.
Power supply (PS) ... provides the electronic power supply for SIMOTION D410 (e.g., SITOP
power supply).
Note:
If the SIMOTION D410 is snapped on to a PM340 Power Module, the Power
Module may be used as the sole method of supplying power to the
SIMOTION D410 in certain cases (e.g. when digital outputs are not used, etc.
. .). Also refer to the Power supply section in the SIMOTION D410 Manual.
