Parameter assignment / addressing
5.5 Configuring an Ethernet subnet
SIMOTION D4x5-2
Commissioning and Hardware Installation Manual, 02/2012
133
● IT communication (SIMOTION IT DIAG, SIMOTION IT OPC XML-DA; as option:
SIMOTION IT Virtual Machine)
● PROFINET basic services (e.g. DCP, LLDP, SNMP)
These PROFINET basic services provide uniform functions for the address assignment
and diagnostics, but do not provide PROFINET IO communication for the connection of
drives, I/O modules, etc.
_setIPConfig / _getIPConfig
The following interface assignment applies for the system functions _setIPConfig /
_getIPConfig:
Table 5- 4 Interface assignment _setIPConfig / _getIPConfig
Availability of the interface
Ethernet interface
D4x5-2 DP D4x5-2 DP/PN
Interface assignment
_setIPConfig / _getIPConfig
(EnumInterfaceID)
X120 P1
PN/IE-OP
x - -
1)
X127 P1
PN/IE
x x IE_01 (0)
X130 P1
PN/IE-NET
x x IE_02 (1)
1)
For D4x5-2 DP, _setIPConfig / _getIPConfig is only available for the interfaces X127 and X130.
Routing
"Services via TCP" are supported for all Ethernet interfaces.
From the two Ethernet interfaces, S7 routing is possible to the
● PROFIBUS interfaces and
● PROFINET interfaces
● As well as between the Ethernet interfaces
IP routing from one Ethernet interface to another, as well as from the PROFINET interface to
the Ethernet interface and vice versa, are not possible.
You can find the MAC addresses on the type plate located on the front of the
SIMOTION D4x5-2.
See also
Further information about routing and the differences between IP and S7 routing can be
found in the
Communication System Manual.
