Parameter assignment / addressing
5.5 Configuring an Ethernet subnet
SIMOTION D4x5-2
Commissioning and Hardware Installation Manual, 02/2012
135
Separate Ethernet interfaces
The Ethernet interfaces are entirely separate and are generally connected to different
networks.
The Ethernet interfaces support:
● S7 routing
● No IP routing
SIMOTION D4x5-2 can, therefore, be connected to the machine user's internal company
network with one interface and the second interface can be used, for example, by the
machine manufacturer for the purpose of remote maintenance.
The Ethernet connection of the D4x5-2 can be configured in HW Config. Proceed as follows
to do this:
1. Open your project.
2. Open HW Config. Double-click the Ethernet port (e.g. X127 P1) to open the "Properties
PNxIE ..." dialog box.
3. You can configure the Ethernet connection in the "Options" tab.
Recommendation: Use the default setting "Automatic setting". With Automatic setting, the
baud rate and duplex operating mode are automatically aligned with the connection
partner. The autocrossing functionality is also available so that you can use crossed and
uncrossed cables.
4. Close the "Properties PNxIE ..." dialog box with "OK".
5. Save and compile the modified hardware configuration.
6. Load the new hardware configuration to the SIMOTION D4x5-2 via PROFIBUS DP /
PROFINET IO / Ethernet.
Shielded twisted pair cables are used for the networking.
● 4- and 8-wire cables can be used for 10/100 Mbit/s
● 8-wire cables must be used for 1000 Mbit/s
Note
With SIMOTION < V4.3, the settings are made via HW Config by double-clicking the D4x5-2
module. The "Properties - D4x5 2" dialog box opens. You can configure the Ethernet
connection in the "Extended Ethernet" tab.
For additional information, refer to the
SIMATIC NET Industrial Twisted Pair and Fiber Optic
Networks
Manual. See the list of references for the order number (this is a separate
document).
For further information about the cabling spectrum for Ethernet, see the
Industrial
Communication IK PI
Catalog.
