Siemens SIMOTION D445

Operator control (hardware)
3.2 SIMOTION CF
3.2.2 CompactFlash slot
Location of the CompactFlash slot
The CompactFlash does not extend beyond the housing. An ergonomic recessed grip
enables the card to be removed.
5HFHVVHGJULSRIWKH
&RPSDFWB)ODVKFDUG
%ODQNLQJSODWH
Figure 3-5 View of control unit with closed protective cover
D4xx
3-10 Manual, 12.2004, 6AU1900-1AJ32-0BA0
