Interfaces
4.7 CompactFlash slot
4.7 CompactFlash slot
4.7.1 Compact Flash slot
Features
Type: 50-pin socket connector
This interface should only be used to insert a special SIMOTION CF.
Consult the relevant references for detailed information about SIMOTION CF.
4.8 Measuring sockets
4.8.1 Measuring sockets X131 - X134
Application
The measuring sockets are used to output analog signals. Any interconnectable signal can
be output to any measuring socket on the control unit.
Caution
The measuring sockets should be used exclusively for servicing purposes.
The measurements may only be performed by appropriately trained specialists.
D4xx
Manual, 12.2004, 6AU1900-1AJ32-0BA0
4-15
