Parameterization 10.99
6SE7087-6KP50 Siemens AG
8-26 Operating Instructions SIMOVERT MASTERDRIVES
1PH7xxx is the new designation of what were formerly 1PA6xxx
motors. The 1PH7xxx and 1PA6xxx data therefore tally.
Input in
P097
Motor order
number (MLFB)
Speed
n
n
[1/min]
Torque
T
n
[Nm]
Current
I
n
[A]
1 1PA6101-4_F 1750 24 9.0
2 1PA6103-4_D 1150 36 9.6
3 1PA6103-4_F 1750 34 12.7
4 1PA6103-4_G 2300 31 15.4
5 1PA6105-4_F 1750 44 16.2
6 1PA6107-4_D 1150 60 16.0
7 1PA6107-4_F 1750 57 20.1
8 1PA6131-4_F 1750 71 23.7
9 1PA6133-4_D 1150 112 27.5
10 1PA6133-4_F 1750 96 33.1
11 1PA6133-4_G 2300 93 42.3
12 1PA6135-4_F 1750 117 40.0
13 1PA6137-4_D 1150 162 40.6
14 1PA6137-4_F 1750 136 53.0
15 1PA6137-4_G 2300 127 53.9
16 1PA6163-4_B 400 227 28.2
17 1PA6163-4_D 1150 208 52.1
18 1PA6163-4_F 1750 185 69.0
19 1PA6163-4_G 2300 158 78.5
20 1PA6163-4_B 400 310 35.6
21 1PA6167-4_D 1150 257 66.4
22 1PA6167-4_F 1750 224 75.2
23 1PA6184-4_B 400 390 51.0
24 1PA6184-4_D 1150 366 89.0
25 1PA6184-4_F 1750 325 122.0
26 1PA6184-4_L 2900 265 158.0
27 1PA6186-4_B 400 506 68.0
28 1PA6186-4_D 1150 485 116.0
29 1PA6186-4_F 1750 465 168.0
30 1PA6186-4_L 2900 333 205.0
31 1PA6224-4_B 400 725 89.0
32 1PA6224-4_D 1150 670 162.0
33 1PA6224-4_F 1750 605 205.0
34 1PA6224-4_L 2900 490 275.0
35 1PA6226-4_B 400 935 116.0
36 1PA6226-4_D 1150 870 200.0
1PH7 (=1PA6)
