Requirements
Connection Establishment to SINAMICS S120
SINAMICS S120 at Technology CPU Entry ID: 21767896
V1.0 Edition 10/28/05 18/58
Copyright © Siemens AG 2005 All rights reserved
SINAMICS S120 und Technologie-CPU V2.0-SP1__05-10-28_13-20_e.doc
This requires the following settings in NetPro:
Table 3-3 Activating “Capability of SIMATIC PC station routing” in NetPro
No. Instruction Note
1.
Open NetPro by selecting
Configure Network.
2.
From the module tree, insert a
PG/PC station in Stations.
3.
Open the properties of the PG/PC
station.
4.
Insert a new interface by clicking
the New button.
