SINAMICS S120
Engineering Information
SINAMICS Engineering Manual – November 2015
Ó Siemens AG
362/528
S120 ALM output
at
400 V or 690 V
Frame size Output
Input current
at
400 V or 690 V
Precharging
resistor R
p
per line phase
(in AIM)
Line current at the beginning of
DC link precharging
(initial rms value)
at
400 V or 690 V
Recommended fuses
(provided externally)
to protect precharging
arm on S120 Chassis
380 V – 480 V 3AC
FX 132 kW 210 A 6.8 Ω 29 A Not required
FX 160 kW 260 A 6.8 Ω 29 A Not required
GX 235 kW 380 A 3.4 Ω 59 A Not required
GX / GXL 300 kW 490 A 3.4 Ω 59 A Not required
HX / HXL 380 kW 605 A 2.2 Ω 91 A 3NE1 817-0 (50 A)
HX 450 kW 745 A 2.2 Ω 91 A 3NE1 817-0 (50 A)
HX / HXL 500 kW 840 A 2.2 Ω 91 A 3NE1 817-0 (50 A)
JX / JXL 630 kW 985 A 1.1 Ω 182 A 3NE1 021-0 (100 A)
JX 800 kW 1260 A 1.1 Ω 182 A 3NE1 021-0 (100 A)
JX / JXL 900 kW 1405 A 1.1 Ω 182 A 3NE1 021-0 (100 A)
500 V – 690 V 3AC
HX / HXL 630 kW 575 A 4.0 Ω 86 A 3NE1 817-0 (50 A)
JX / HXL 800 kW 735 A 2.0 Ω 172 A 3NE1 021-0 (100 A)
HXL 900 kW 810 A 2.0 Ω 172 A 3NE1 021-0 (100 A)
JX / JXL 1100 kW 1025 A 2.0 Ω 172 A 3NE1 021-0 (100 A)
JX / JXL 1400 kW 1270 A 2.0 Ω 172 A 3NE1 021-0 (100 A)
JXL 1700 kW 1560 A 1.33 Ω 259 A 3NE1 021-0 (100 A)
S120 Active Infeed: Line currents at the beginning of precharging (initial rms values)
