Siemens SINUMERIK 808D Operating Guide

808D Page 29 Operating and Programming — Milling
Create Part
Program
Part 1
s
Basic Theory
Content
Unit Description
This unit describes how to create a part program, edit the part program
and get to know the most important CNC commands required to produce
a workpiece.
Unit Content
Program
structure
Create
program
Edit
program
Imperial
and Metric
system
Definition
of target
position
Rapid
motion
Tools and
motion
Behaviors
at corners
Milling
circles and
arcs
Moving to a
fixed
position
Controlling
the spindle
Setting a
delay in the
program
Program
structure
A standard program structure is not needed but is
recommended in order to provide clarity for the
machine operator. Siemens recommends the
following structure:
Header
T, F, S function
Geometry data / motion
Return to change tool
T, F, S function
Geometry data / motion
Return to change tool
T, F, S function
Geometry data / motion
Return to change tool
End/stop motion
N5 G17 G90 G54 G71
N10 T1 D1 M6
N15 S5000 M3 G94 F300
N20 G00 X100 Y100 Z5
N25 G01 Z-5
N30 Z5
N35 G00 Z500 D0
N40 T2 D1 M6
N45 S3000 M3 G94 F100
N50 G00 X50 Y50 Z5
N55 G01 Z-5
N60 Z5
N65 G00 Z500 D0
N70 T3 D1 M6
N75 S3000 M3 G94 F100
N80 G00 X50 Y50 Z5
N85 G01 Z-5
N90 Z5
N95 G00 Z500 D0
N100 G00 G40 G53 X0 Y0 Z500 D0
M30
End
