Siemens SINUMERIK 828D Training Manual

1 Brief description
Sinumerik 828D
This document was produced for training purposes.
Siemens assumes no responsibility for its contents.
SINUMERIK 828D Page 1
B060
B060
System Overview
B060
Module Objective:-
Upon completion of this module you will know the Sinumerik 828D system and the components which
make up the system.
Module Description:-
The Sinumerik 828D system is made up of a variety of hardware components. This module gives a
graphical overview of those components and shows where each component is connected.
A brief description of the hardware components is also given.

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
