Siemens SINUMERIK 840D Diagnostic Manual

NCK alarms
11/2006 Overview of Alarms
2-601
© Siemens AG, 2006. All rights reserved
SINUMERIK, SIMODRIVE Diagnostics Manual (DA), 11/2006 Edition
75200 RCTR: incorrect MD configuration, channel %1, error in MD: %2
Parameters: %1 = Channel number
%2 = MD name
Definitions: The following error was detected in the handling transformation machine data:
TRAFO6_IRORO: The orientation entered in MD TRAFO6_TIRORO_RPY is impermissible.
TRAFO6_TFLWP: The orientation entered in MD TRAFO6_TFLWP_RPY is impermissible.
TRAFO6_TX3P3: The orientation entered in MD TRAFO6_TX3P3_RPY is impermissible.
TRAFO6_MAIN_LENGTH_AB: The value entered in MD TRAFO6_MAIN_LENGTH_AB is incorrect.)
Reaction: Mode group not ready.
Channel not ready.
NC Start disable in this channel.
Alarm display.
Remedy: Correct machine data
Program
Continuation:
Switch control OFF - ON.
75210 RCTR: Channel: %1, number of axes/axis assignment inconsistent
Parameters: %1 = Channel number
Definitions: On transformation selection an incorrect axis assignment is detected:
The axes entered in MD TRAFO_AXES_IN_1 do not match MD TRAFO6_NUM_AXES.
Reaction: Interpreter stop
Alarm display.
Remedy: Correct machine data.
Program
Continuation:
Clear alarm with the RESET key. Restart part program
75212 RCTR: channel %1, incorrect TRAFO_TYPE_ : use 4100
Parameters: %1 = Channel number
Definitions: The transformer type entered in MD TRAFO_TYPE_x is incorrect
Reaction: Interpreter stop
Alarm display.
Remedy: TRAFO_TYPE 4100 is to be used
Program
Continuation:
Clear alarm with the RESET key. Restart part program
75250 RCTR: channel %1, tool parameters incorrect interpreter
Parameters: %1 = Channel number
Definitions: On block interpretation incorrect tool parameters are detected:
Reaction: Interpreter stop
Alarm display.
Remedy: Correct tool parameters.
Program
Continuation:
Clear alarm with the RESET key. Restart part program
75255 RCTR: channel: %1, unreachable position interpreter
Parameters: %1 = Channel number
Definitions: On block interpretation a non-approachable position is detected:
Reaction: Interpreter stop
Alarm display.
Remedy: Modify part program.
Program
Continuation:
Clear alarm with the RESET key. Restart part program
