840D/828D SINUMERIK Operate
Notes
Section 2
Operating mode "JOG"
The following functions are offered in the horizontal and vertical softkey
bar of the operating area "Machine" ( see section 2.2 and 2.3).
2.2 Vertical softkey bars 1 and 2
Display area Description
The most important G-functions are displayed in a
subwindow by pressing the VSK 1.1 "G functions".
Available auxiliary functions are displayed in a sub-
window by pressing the VSK 1.2 "Auxiliary func-
tions" at the time of the output.
switch over from the machine coordinate system
(MCS) to the workpiece coordinate system (WCS).
Note the machine manufacturer„s documentation.
By pressing the VSK 1.8 "Forward" on the operator
panel (OP) the selection of additional softkeys on
the vertical softkey bar is possible
By pressing the VSK 2.2 "All G functions" all G-
functions will be shown.
