840D/828D SINUMERIK Operate
Notes
Section 7
Position
7.3. Parameters of "Target position"
F [mm/
min]
[mm/
rev]
Feed
X
Y
Z
Z2
[mm]
Target position [abs/inc]
Note:
The number of the axes is depending on the
machine configuration.
Note the machine manufacturer„s documen-
tation.
C
AWZ
SP2
[Degree] Target angle [abs/inc]
7.4. Method for “Target position“
1. If required, select a tool.
2.
3.
4. Enter the target position or target angle for the axis
or axes to be traversed.
5.
- OR -
5. Press VSK 5 "Rapid".
6. Press the "CYCLE START" button on the machine
control panel.
The axis is traversed to the specified target position.
If target positions were specified for several axes, the axes are traversed
simultaneously.
