Section 3
Options in the editor
3.1 Horizontal softkey bar:
In this section the general functions of the programming with the
SINUMERIK Operate will be described.
More information is available in the corresponding modules.
By pressing the HSK 2 “Drill.“ the following cycles for
drilling will be called up:
Centering
Drilling and Reaming
Deep hole drilling
Boring
Thread
Positions
Position repetitions
See module B610 and B611 “Drilling“.
By pressing the HSK 3 “Turning“ the following cycles
for turning will be called up:
Stock removal
Groove
Undercut
Thread
Cutoff
See module B625, B626, B633 and B634 “Turning”.
By pressing the HSK 4 “Cont. turn.“ the following cy-
cles for contour turning will be called up:
Contour
Stock removal
Cut residual stock
Grooving
Groove residual
Part
Part residual
