B524 Page 8 840D/828D SINUMERIK Operate
Notes
Section 3
By pressing the HSK 5 “Milling“, the following cycles
for milling will be called up:
Face milling
Pocket
Multi-edge spigot
Slot
Thread milling
Engraving
Contour milling
See module B617 and B618 “Milling“.
By pressing HSK 6 „Various“ the following functions
will be called up:
Blank
HighSpeedSettings
Subprogram
See module B601 and B605 - “Basics of program-
ming“.
By pressing the HSK 7 “Simulation“ the program run
and the machining of the workpiece can be simu-
lated.
Different views on the simulated workpiece are avail-
able:
Side view
Face view
Further views
Details
Program control
Show tool path
Delete tool path
Blank
See module B601 and B605 - “Basics of program-
ming“.
Press the HSK 8 "NC Select" or “Execute” to change
to the operating area “Machine” and to start the ma-
chining of the program.
See module B601 and B605 - “Basics of program-
ming“.
Options in the editor
