B506 Page 6 840D/828D SINUMERIK Operate
Notes
Section 5
For the user it may be advantageous to switch on certain settings, that are
to be activated in the part program, already in the program heading.
If necessary, these modally operative commands can always be reset by
other commands at any stage during the program.
Programming example: Explanation:
N10 G17 G54 G64 G71 G90 G94 X/Y-plane, 1
st
ZP-offset,
continuous control, metrical
system, absolute dimensions,
linear feed rate F in mm/min,
N20….
….
Suggestion of a program heading for a turning application:
Programming example: Explanation:
N10 G18 G54 G64 G71 G90 G96 Z/X-plane, 1
st
ZP-offset,
continuous control, metrical
system, absolute dimensions,
constant cutting speed S in m/
min
N20 DIAMON LIMS=3000 Diameter input
*
, speed limitation
n
max
=3000 min
-1
N30
….
Note:
As the tool progresses towards the centre during facing, the spindle speed
evaluated internally in the control unit increases steadily until eventually
the maximum possible spindle speed would be attained.
Depending on the clamping conditions and the size of the work piece a
speed limitation should always be selected for reasons of safety.
* The explanation of the diameter input will be found in section 6 of this
manual.
Settings at the start of a program
