Dimensioning for the X-axis
Effect of the command “DIAMON” under G90:
Effect of the command “DIAMON” under G91:
Programming example : Explanation:
N70 ….
N80 G90 DIAMON; Absolute dimension, diameter progr. ON
N90 G01 X0 Z0; Starting position on diameter 0
N100 X30; Motion to diameter 30
N110 Z-10; Motion in Z
N120 X60; Motion to diameter 60
N130….
Programming example : Explanation:
N70 ….
N80 G90 DIAMON; Absolute dimension, diameter progr. ON
N90 G01 X0 Z0; Original position to diameter 0
N100 G91; Incremental dimension
N110 X30; Motion by diameter 30
N120 Z-10
N130 X30; Motion by diameter 30
N140 G90; Switching back to absolute dimensions
N150 ….
N130 Motion by the diameter 30
N110 Motion by the diameter 30
N90 Original position of the tool
N120 Motion to the diameter 60
N100 Motion to the diameter 30
N90 Original position of the tool
