01.91 9 Examples
9.2.18 FB 179 Tools selected according to cursor position
Data structure
Address key Comment
DL
FW 224 Auxiliary flag
FW 226 Status word
FW 228 Auxiliary flag
FW 252 Auxiliary flag
FW 254 Auxiliary flag
DB 145, DW 95
DR
Disable bits
Unassigned
Address key Comment
DL
DW 95 Status byte
DW 96 T number
DW 97 T number
DW 98 Duplo number
DW 99 Identification 1 (search key DB 151)
DW 100 Identification 2 (search key DB 152)
DW 101 Screen form 2 for identification 2
DW 102 Bit No. Cursor
DW 103 DB No. Cursor
DW 104 DW No. Cursor
DW 105 Magazine No.
DW 106 Magazine No.+1
DR
Disable bits
Locator No.+1
Locator No.
Unassigned
Pointer No. of mag.
Prog. channel
