11.92 10 Data Fields
10.2.1 NC machine data
Channel-specific values
104*
TO area for channel
104*
+
1 to 16
1)
1 -
Sign Units StepsInput limits Default value
* ... 0 Channel 1
:
15 Channel 16 for SINUMERIK 880/880 GA2; 0..3 for SINUMERIK 840/840C
The TO area of every channel available must be entered.
The TO area specifications have to match the TO area definition of the
PLC machine data; however, only TO area 1 is possible for all channels.
No validity check is made between NC and PLC machine data.
_______
1) In the case of SINUMERIK 840/840C, the value 4 applies.
© Siemens AG 1991 All Rights Reserved 6FC5 197-0AA40-1BP1 10–11
SINUMERIK 840/880 (PJ)
