Description
2
The red emergency stop mushroom pushbutton has a yellow ring.
Directly under the mushroom pushbutton, there is also a green ring, which identies the
position status of the emergency stop button.
State
Ring (green) Visible Not visible
Emergency stop button Not pressed Pressed
Emergency stop button
Equipment Manual, 10/2020, A5E49939755B AA 13
