Assembly and Installation Information
SIPART DR22/DR24
C79000-M7474-C38-01
15
4 Important Technical Data
Mounting position Any
Climatic class of application during
operation
3k3 DIN/IEC 721 T3-3
Permissible environmental temperature during
operation
0to50°C
Protection category according to
Operating and display unit
Housing / terminal clamps
EN 60529
IP 64
IP30 / IP20
Dimensions See ”Mechanical Installation”
Power supply AC (switchable) 115 V ~/ 230 V~15%
47 to 63 Hz
Max. power consumption 15 W / 19 V A
Power supply UC 24 V =/~
DC 20 to 28 V
AC 24 V ~15%;47to63Hz
Analog inputs AE1 to AE3
Current
rated signal range
control range
input resistance
common-mode voltage
Isolated up to 10 V
0/4to20mA
-1 to 21 mA
49.9 Ohm
0to+10V
Voltage
rated signal range
input resistance
0/199.6 to 998 mV or 0/2 to 10 V
> 200 KOhm
Analog outputs AA1 to AA3
rated signal range
load voltage
Non-floating
0/4to20mA
From -1 to 18V
Binary inputs
signal state 0
signal state 1
static destruct limit
Non-floating
≤4.5 V
≥13 V
35 V
Binary outputs
signal state 0
signal state 1
load current
Non-floating
≤1.5 V
+19to26V
≤50 mA
Controller design - in accord. with EN 61010 part 1
- Protection category I according to
IEC 536
- Outputs are small function voltages
CE marking EC Conformity Declaration no.
DR22/24-2/98
