1 Technical Description
1.6 Technical Data
1.6.1 General Data
Manual
94
SIP ART DR24 6DR2410
C79000-G7476-C153-03
Relay module
6DR2804-8A/B
max. 40
8
238
278
72
144
130
1)
Installation depth required to change the motherboard
435
1)
223
Figure 1--42 Dimensions SIPART DR24, dimensions in mm
138
+1
68
+0.7
72.5
+1
b
≥145
1)
1)
Installation close one above the other is allowed when the permissible ambient temperature is observed.
Number of
controllers Cut-out width b
2 140 +1
3 212 +1
4 284 +1
:
:
:
10 716 +1
Figure 1--43 Panel cut--outs, dimensions in mm
