Integrated Power Supply
1/3 base module, modular
Without plug-in modules
13 W 33 VA 24 VA
1/6 expansion module 3 W 6 VA 6 VA
1/6 plug-in module
assembly without plug-in
modules (modules CB202)
3.5 W 14 VA 7 VA
Plug-in module for base
module or plug-in module
assembly (for example,
communication module)
< 5 W < 6 VA < 6 VA
Stored-energy time for auxiliary voltage outage or
short circuit, modular devices
For V ≥ DC 24 V ≥ 50 ms
For V ≥ DC 110 V ≥ 50 ms
For V ≥ AC 115 V ≥ 50 ms
Stored-energy time for auxiliary voltage outage or
short circuit, non-modular devices
For V ≥ DC 24 V ≥ 20 ms
For V ≥ DC 60 V/DC 110 V ≥ 50 ms
For V ≥ AC 115 V ≥ 200 ms
Binary Inputs
Rated voltage range DC 24 V to 250 V
The binary inputs of SIPROTEC 5 are bipolar with the exception of the
binary inputs on the IO230 and on the IO231.
Current consumption, excited Approx. DC 0.6 mA to 1.8 mA (independent of the operating voltage)
Power consumption, max. 0.6 VA
Pickup time Approx. 3 ms
Dropout time Approx. 4 ms
Switching thresholds Adjustable with DIGSI 5
Range 1 for 24 V, 48 V, and 60 V
Operating voltage
V
low
≤ DC 10 V
V
high
≥ DC 19 V
Range 2 for 110 V and 125 V
Operating voltage
V
low
≤ DC 44 V
V
high
≥ DC 88 V
Range 3 for 220 V and 250 V
Operating voltage
V
low
≤ DC 88 V
V
high
≥ DC 176 V
Maximum permitted voltage DC 300 V
The binary inputs contain interference suppression capacitors. In order to ensure EMC, use the terminals
shown in the terminal diagrams/connection diagrams to connect the binary inputs to the common potential.
Relay Outputs
Standard Relay (Type S)
Switching capacity
On: 1000 W/VA
Off: 30 VA; 40 W ohmic;
30 W/VA at L/R ≤ 40 ms
AC and DC contact voltage 250 V
Permissible current per contact (continuous) 5 A
Permissible current per contact (switching on and
holding)
30 A for 1 s (make contact)
11.1.3
11.1.4
Technical Data
11.1 General Device Data
558 SIPROTEC 5, Low-Impedance Busbar Protection 7SS85, Manual
C53000-G5040-C019-6, Edition 06.2016
