Frequency range (expanded) 40 Hz to 60 Hz at f
rated
= 50 Hz
50 Hz to 70 Hz at f
rated
= 60 Hz
Tolerance 0.3 % of the measured value in the above mentioned
measuring range
Frequency
Frequency f Hz
Range f
rated
- 0.20 Hz < f
rated
+ 0.20 Hz
Tolerance ± 5 mHz in the V
rated
range
Range f
rated
- 3.00 Hz < f
rated
+ 3.00 Hz
Tolerance ± 10 mHz in the V
rated
range
Frequency range (expanded) 25 Hz to 80 Hz; operational measured values
10 Hz to 80 Hz; functional measured values, system
frequency
Tolerance 20 mHz in the range f
rated
± 10 % for rated values
Statistical Values of the Device
Device operating hours h
Range 0 to 9 999 999 h
Tolerance 1 h
Statistical Values of the Circuit Breaker
Op.cnt.
(operation counter)
Range 0 to 999 999 999
Tolerance None
∑I Off (sum of the primary currents switched off)
A, kA, MA, GA, TA, PA primary
Range 0 to 9.2 e+15
Operating hours h
Range 0 to 9 999 999 h
Tolerance 1 h
Circuit breaker open hours h
Range 0 to 9 999 999 h
Tolerance 1 h
Statistical Values of the Disconnector
Op.cnt.
(operation counter)
Range 0 to 999 999 999
Tolerance None
Technical Data
11.34 Operational Measured Values and Statistical Values
616 SIPROTEC 5, Low-Impedance Busbar Protection 7SS85, Manual
C53000-G5040-C019-6, Edition 06.2016
