Siemens SIPROTEC 5 Hardware Description Manual

Dropout time
21
Capacitive load (supply-line capaci-
tance)
Dropout time
< 5 nF < 3 ms
< 10 nF < 4 ms
< 50 nF < 5 ms
< 220 nF < 10 ms
Control voltage for the module
IO216
Range for 220 V control voltage
Threshold pickup 158 V to 170 V
Threshold dropout 132 V to 154 V
Maximum permitted voltage DC 300 V
The binary inputs contain interference suppression capacitors. To ensure EMC immunity, use the terminals
shown in the terminal diagrams/connection diagrams to connect the binary inputs to the common potential.
21
For time-critical applications with low-active signals, consider the specified dropout times. If necessary, provide for active discharge
of the binary input (for example, a resistor in parallel to the binary input or using a change-over contact).
Technical Data
6.3 Binary Inputs
212 SIPROTEC 5, Hardware Description, Manual
C53000-G5040-C002-F, Edition 06.2019
