Siemens SIPROTEC 5 Hardware Description Manual

Standard for Withstand Capability
or Relay Systems to Radiated Elec-
tromagnetic Interference from
Transceivers (Keying test)
IEEE Std C37.90.2
20 V/m
80 MHz to 1 GHz
Pulse modulation (not valid for IO216)
Damped oscillatory wave immunity
test
IEC 61000-4-18
100 kHz, 1 MHz, 2.5 kV (peak value)
3 MHz, 10 MHz, 30 MHz, 2 kV (peak value)
Test duration ≥ 60 s
Power-frequency disturbance test
at binary inputs
IEC 61000-4-16
Zone A
150 V (differential mode)
300 V (common mode)
EMC Electromagnetic Emission Tests (Type Tests, Test under Mounting Conditions)
Standards IEC 60255-26 (product standard)
IEC 61000-6-4 (generic standard)
Conducted emission on auxiliary-voltage lines
CISPR 22
150 kHz to 30 MHz limit class A
Radiated emission CISPR 11 30 MHz to 1 000 MHz limit class A
CISPR 22 1 GHz to 6 GHz limit class A
Loading effect in electricity-supply systems, harmonics
Harmonic current emissions
Does not apply!
(see EN 61000-3-2, section 7,
power consumption < 75 W)
Loading effect in electricity-supply systems, voltage fluctuations
Flicker
Does not apply!
(see EN 61000-3-3, section 6, no
significant voltage fluctuations)
Technical Data
6.7 Electrical Tests
222 SIPROTEC 5, Hardware Description, Manual
C53000-G5040-C002-F, Edition 06.2019

Siemens SIPROTEC 5 Specifications

General

Series	SIPROTEC 5
Communication Protocols	IEC 61850, DNP3, Modbus
Cybersecurity	Role-based access control, secure communication
Modular Design	Yes
Hardware Redundancy	Optional
Operating Temperature	-25°C to +70°C
Digital Inputs	Configurable, number depends on I/O modules
Digital Outputs	Configurable, number depends on I/O modules
Analog Inputs	Configurable, number depends on I/O modules
Current Transformer Inputs	Configurable, number depends on I/O modules
Voltage Transformer Inputs	Configurable, number depends on I/O modules
Time Synchronization	IRIG-B, SNTP, PTP
Protection Functions	Overcurrent, Differential, Distance, Over/Under Voltage, Frequency
Housing	19-inch Rack Mount
Dimensions	Depends on module configuration
Weight	Depends on module configuration
Voltage Input	24V DC, 48V DC, 110V DC, 125V DC, 220V DC, 250V DC
