SIPROTEC PROFIBUS-DP - Communication profile
C53000-L1840-B001-03
function
Figure 1-2 Display of module-specific information at the device
PROFIBUS-DP
Slave : 2
Status: DATA_EXCHG
PNO-Id: 80BChex
Master: 1
Baudr.: 1.5 MB/s
SlvWDT: 70 ms
TimeSy: C355F7A6hex
DP_SW : V04.00.06
MapNo.: 3-1
MapRev: V01.00.05
Module: PSO2-GEN
HWCode: 0Chex
HWRev.: 04
BF-No.: 0310042351
Ld_Jmp: V01.00.05
OLMStA: OK
OLMStB: Error
OLMLed: G Y R
OLMCmp: V2, OLM/S4
OLMMod: Redundancy
OLMNWS: Standard
EvSize: 500
EvEntr: 0/0
EvCtrl: 00h-00h T-R
******* END ********
PORT B
---------------------
Block 5:
Status of the “Event list via PROFIBUS-DP”.
Block 5 is only available if the selected mapping file sup-
ports an “Event list via PROFIBUS-DP” (ref to chap. 2.5).
Block 3:
Module hardware information and version number of
the boot firmware.
Block 2:
PROFIBUS-DP firmware version as well as number and
version of the selected mapping file.
Block 1:
Status and parameters of the PROFIBUS-DP slave.
Block 4:
OLM information
Block 4 is only available for fibre-optical PROFIBUS
modules.
