PROFIBUS Communication modules
15
SIPROTEC PROFIBUS-DP - Communication profile
C53000-L1840-B001-03
1.2 Display of module-specific information at the SIPROTEC device
The display of module-specific information is accessible with the following menu items
or buttons:
• MENU
• Test/Diagnosis → 5
• Modulinfo → 5
• Port B → 1
The maximum number of displayed information, separated in five blocks, is shown in
Figure 1-2.
Depending on the used communication module type and the selected mapping file
(and the resultant functional range) the blocks 4 and 5 are not existing.
The data in the individual information blocks are explained in the following chap. 1.2.1
to 1.2.5.
Note:
The following prerequisites are necessary for using the functionality “Display of
module-specific information at the SIPROTEC device”:
• PROFIBUS communication module from HW revision 4 with PROFIBUS-DP firm-
ware from V04.00,
• SIPROTEC device firmware which supports this function, e.g.:
• 7SJ61...7SJ64, 6MD63 device firmware from V4.50,
• 6MD663/6MD664 device firmware from V4.50,
• 7SA522, 7SA6 device firmware from V4.50.
Changing parameters for the PROFIBUS-DP slave of the SIPROTEC device is exclu-
sively possible using the DIGSI parameterization system.
If the display of module-specific information is not supported by the firmware of the
used SIPROTEC device then the below-mentioned menu items are not offered for
selection.
If a PROFIBUS communication module up to HW revision 3 is used, then in a SIPRO-
TEC device with above-mentioned firmware V4.50 the following text is displayed in
case of selecting the menu item for display of module-specific information:
**** LIST EMPTY ****
The values in the display of module-specific information are actualized every 500 ms.
It is therefore possible that short-time changes of information are not displayed.
