Data type definitions
53
SIPROTEC PROFIBUS-DP - Communication profile
C53000-L1840-B001-03
3.8 Transformer tap position indication (TM)
Number of
byte-values
1
Range of values 1 to 62
(63 = 3F
hex
= invalid transformer tap change value via binary inputs)
Figure 3-8 Data type: Transformer tap position indication
Status bit (S) In the event of a set status bit the transformer tap position indication is invalid, as no
relevant binary inputs are allocated in DIGSI.
In conjunction a transformer tap position value of 0 is transmitted.
Byte
= 0
Message head...
...Message end
Transformer tap position value
2
0
2
5
2
6
2
7
...
S
