Technical Data
Load Capability of the Voltage Divider
Description Value
Max. permissible continuous voltage 2000 V DC (Terminal C); 1500 V DC (UL)
600 V DC (Terminal B)
Max. dissipated power 3.5 W
Weight
The weight of the device is 2.2 kg (4.9 lb.).
4.4
4.4.1
4.4.2
7XR87 Voltage Divider for Excitation Voltage
4.4 Technical Data
SIPROTEC, Coupling Units for Generator Protection, Manual 55
C53000-H5040-C072-1, Edition 09.2018
