Electrical Tests
Standards
IEC 60255 (product standard)
Additional standards are listed for the individual tests.
Installation Requirements
Overvoltage category III
Degree of pollution 2
Protection class 1
Insulation and Safety Tests
Standards IEC 60255-27
Voltage test (routine test) DC 2.8 kV, 1 s (output)
Voltage test (routine test) DC 4.8 kV, 1 s (input)
Surge immunity test (type testing), all circuits 8 kV (peak value), 1.2 µs/50 µs, 0.5 J
3 positive and 3 negative impulses at intervals of 1 s
Insulation resistance > 100 MΩ @ DC 500 V
Resistor of protective equal-potential-bonding < 0.1 Ω @ DC 12 V, 30 A after 1 min
NOTE
For the insulation tests of the generator according to IEC60034-1 or IEEE421.3, the device has to be discon-
nected from the generator if the applied voltage is higher than the values shown here.
EMC Immunity Tests (Type Tests, Test under Mounting Conditions)
See 1.6.4 EMC Immunity Tests (Type Tests, Test under Mounting Conditions) for 7XR81.
4.5
4.5.1
4.5.2
4.5.3
4.5.4
7XR87 Voltage Divider for Excitation Voltage
4.5 Electrical Tests
56 SIPROTEC, Coupling Units for Generator Protection, Manual
C53000-H5040-C072-1, Edition 09.2018
