SIRIUS 3RT2 contactors/contactor assemblies
2.2 Product description
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
107
2.2.2.2 3RT2 power contactors
The table below shows the different versions of the 3RT2 power contactors. The contactors
are equipped with AC and DC drive options. An electronic UC drive can also be ordered for
size S0. Special communication-capable contactors are available for integration via
AS-Interface or IO-Link by means of 3RA27 function modules; these contactors enable the
voltage of the main circuit to be tapped directly. The communication-capable power
contactor is supplied with a 24 V DC drive option.
Versions
Table 2- 5 Versions of the 3RT2 power contactors
Feature Specifications
Version Power contactor
for switching
electrical loads
Power contactor
with extended
operating range
Coupling relay for
switching
electrical loads
3RT23 power
contactor for
switching resistive
loads
3RT25 power
contactor with
2 NO contacts
and 2 NC contacts
Number of poles 3 3 3 4 2 NO contacts +
2 NC contacts
S00 1 NO contact or
1 NC contact
1 NO contact or
1 NC contact
1 NO contact or
1 NC contact
--- --- Number of
integrated
auxiliary
contacts
S0 1 NO contact and
1 NC contact
1 NO contact and
1 NC contact
1 NO contact and
1 NC contact
1 NO contact and
1 NC contact
1 NO contact and
1 NC contact
Size S00/S0
Width 45 mm
Connection systems
The power contactors can be supplied with the connection systems detailed below:
Table 2- 6 Connection systems available for 3RT2 power contactors
Connection
system
Power contactor for
switching electrical
loads
Power contactor with
extended operating
range
Coupling relay for
switching electrical
loads
3RT23 power contactor
for switching resistive
loads/3RT25 power
contactor with 2 NO
contacts and 2 NC
contacts
Screw connection ✓ ✓ ✓ ✓
Spring-loaded
connection
✓ ✓ ✓ ✓
Ring cable lug
connection
✓ --- --- ---
Solder pin
connection (only
possible in
conjunction with
the "solder pin
adapter" optional
accessory)
✓
(size S00 only)
✓
(size S00 only)
✓
(size S00 only)
---
