SIRIUS 3RT2 contactors/contactor assemblies
2.7 Accessories
SIRIUS Innovations
158 System Manual, 01/2011, A8E56203870002-03
Size-specific accessories for 3RT2 contactors (size S00)
1 Contactor size S00
2 Laterally mountable auxiliary switch block (right or left), 2-pole
3 Auxiliary switch block for snapping onto the front, 1-pole (cable entry from above or below)
4 Auxiliary switch block for snapping onto the front, 2-pole (cable entry from above or below)
5 Auxiliary switch block for snapping onto the front, 4-pole
6 3RA28 function modules
7 Function module for AS-Interface, direct-on-line start
8 Function module for IO-Link, direct-on-line start
9 Surge suppressor
10 3-phase infeed terminal
11 Star jumper, 3-pole, without connection terminal
12 Parallel switching connector, 3-pole or 4-pole, with connection terminal
13 Wiring modules on the top and bottom, for connecting the main and control current paths
14 Solder pin adapter
15 Terminal module (adapter) for contactors with screw connections
Figure 2-23 Size-specific accessories for 3RT2 contactors (size S00)
